Molding Tool Design For Automotive Component

Design and development of tooling for aluminum pressure die casting automotive parts.

Contact Us

About Project

Design and development of tooling for aluminum pressure die casting automotive parts.

Project development includes the following.

  • Draft correction on 3D CAD

  • Identification of parting lines and sprue bushing

  • Shrinkage inclusion

  • Design of tooling including tapper pins, ejector pins, cooling channels

  • CNC Programming of 3 axis milling machine,

  • identification of gauge errors and interferences

  • Tool bit selection

  • Post processing the CNC programs

  • Design of EDM tool for complex corners

    • Technologies Used & Time Duration

    PTC Creo manufacturing

    Time Duration : 3-4 months
